Model
|
PS12B
|
PS12BA
|
PS15B
|
PS15BA
|
|
Type
|
12" 2 way
full range passive system
|
12" 2 way
full range active system
|
15" 2 way
full range passive system
|
15" 2 way
full range active system
|
|
Grill Color
|
Black/white
|
Black/white
|
Black/white
|
Black/white
|
|
Cabinet
|
MDF, Painted finish
|
MDF, Painted finish
|
MDF, Painted finish
|
MDF, Painted finish
|
|
LF driver
|
1*12inch, 2.5"VC,50 OZ
magnet,steel basket
|
1*12inch, 2.5"VC,50 OZ
magnet,steel basket
|
1*15inch, 3"VC,60 OZ
magnet,steel basket
|
1*15inch, 3"VC,60 OZ
magnet,steel basket
|
|
HF driver
|
1.35" VC Titanium
|
1.35" VC Titanium
|
1.75" VC Titanium
|
1.75" VC Titanium
|
|
Sensitivity
|
96dB
|
96dB
|
98dB
|
98dB
|
Frequency
Range
|
50-20KHz
|
50-20KHz
|
45-20KHz
|
45-20KHz
|
|
RMS Power
|
300W
|
350W
|
400W
|
350W
|
|
Max Power
|
600W
|
700W
|
800W
|
700W
|
|
Impedance
|
8 Ohm
|
8 Ohm
|
8 Ohm
|
8 Ohm
|
|
Crossover
|
2.5KHz
|
2.5KHz
|
2.5KHz
|
2.5KHz
|
Carton
Dimension
|
49*41*66cm
|
49*41*66cm
|
49*47*77cm
|
49*47*77cm
|
|
Pcs/Carton
|
1PC
|
1PC
|
1PC
|
1PC
|
|
N.W
|
17kg
|
20kg
|
23kg
|
26kg
|
|
G.W
|
19kg
|
22kg
|
26kg
|
29kg
|
|
Model
|
PS215B
|
PS215BA
|
PS12FMA
|
PS15FMA
|
|
Type
|
15" 3 way
full range passive system
|
15" 3 way
full range active system
|
12" 2 way
full range active system
|
15" 2 way
full range active system
|
|
Grill Color
|
Black/white
|
Black/white
|
Black/white
|
Black/white
|
|
Cabinet
|
MDF, Painted finish
|
MDF, Painted finish
|
MDF, Painted finish
|
MDF, Painted finish
|
|
LF driver
|
2*15inch, 3"VC,60 OZ
magnet,steel basket
|
2*15inch, 3"VC,60 OZ
magnet,steel basket
|
1*12inch, 2.5"VC,50 OZ
magnet,steel basket
|
1*15inch, 3"VC,60 OZ
magnet,steel basket
|
|
HF driver
|
1.75" VC Titanium
|
1.75" VC Titanium
|
1.35" VC Titanium
|
1.75" VC Titanium
|
|
Sensitivity
|
99dB
|
99dB
|
96dB
|
98dB
|
Frequency
Range
|
40-20KHz
|
40-20KHz
|
50-20KHz
|
45-20KHz
|
|
RMS Power
|
800W
|
600W
|
350W
|
350W
|
|
Max Power
|
1600W
|
1200W
|
700W
|
700W
|
|
Impedance
|
8 Ohm
|
8 Ohm
|
8 Ohm
|
8 Ohm
|
|
Crossover
|
1.8KHz
|
1.8KHz
|
2.5KHz
|
2.5KHz
|
Carton
Dimension
|
49*47*127cm
|
49*47*127cm
|
39*37*58cm
|
48*45*72cm
|
|
Pcs/Carton
|
1PC
|
1PC
|
1PC
|
1PC
|
|
N.W
|
40kg
|
43kg
|
17kg
|
22kg
|
|
G.W
|
42kg
|
45kg
|
19kg
|
24kg
|
|
Model
|
PS15SUB-D
|
PS18SUB-D
|
PS218SUB
|
|
Type
|
15" active subwoofer
|
18" active subwoofer
|
Double 18" passive subwoofer
|
|
Grill Color
|
Black/white
|
Black/white
|
Black/white
|
|
Cabinet
|
MDF, Painted finish
|
MDF, Painted finish
|
MDF, Painted finish
|
|
LF driver
|
1*15inch, 4"VC,125 OZ
magnet,Aluminium basket
|
1*18inch, 4"VC,125 OZ
magnet,Aluminium basket
|
2*18inch, 4"VC,125 OZ
magnet,Aluminium basket
|
|
HF driver
|
None
|
None
|
None
|
|
Sensitivity
|
97dB
|
96dB
|
96dB
|
|
Frequency Range
|
35-300HZ
|
35-300HZ
|
30-300HZ
|
|
RMS Power
|
500W
|
600W
|
1000W
|
|
Max Power
|
1000W
|
1200W
|
2000W
|
|
Impedance
|
8 Ohm
|
8 Ohm
|
8 Ohm
|
|
Crossover
|
150Hz
|
150Hz
|
120Hz
|
|
Carton Dimension
|
60*55*55cm
|
69*59*62cm
|
108*75*63cm
|
|
Pcs/Carton
|
1PC
|
1PC
|
1PC
|
|
N.W
|
30kg
|
38kg
|
72kg
|
|
G.W
|
32kg
|
41kg
|
75kg
|
|
