Model
|
PC12FM
|
PC15FM
|
PC215F
|
|
Type
|
2 way ,
full arrange passive systerm
|
2 way ,
full arrange passive systerm
|
3 way ,
full arrange passive systerm
|
|
Cabinet
|
MDF ,Painted finish
|
MDF ,Painted finish
|
MDF ,Painted finish
|
|
LF driver
|
1x 12inch, 2.5"VC,
50 Oz magnet,steel basket
|
1x 15 inch, 3"VC,
60 Oz magnet,steel basket
|
2x 15 inch, 3"VC,
60 Oz magnet,steel basket
|
|
HF driver
|
1.35 VC Titanium
|
1.75"VC Titanium
|
1.75"VC Titanium
|
|
Sensitivity
|
96dB
|
98dB
|
101dB
|
Frequency
response
|
50-20Khz
|
45-20Khz
|
40-20Khz
|
|
RMS Power
|
300 W
|
350 W
|
600W
|
|
Max Power
|
600 W
|
700 W
|
1200W
|
|
Impedance
|
8 Ohm
|
8 Ohm
|
8 Ohm
|
|
Crossover
|
2.5Khz
|
2.5Khz
|
1.8Khz
|
|
Model
|
PC18SUB
|
PC218SUB
|
PC12F
|
|
Type
|
passive subwoofer
|
passive subwoofer
|
2 way ,
full arrange passive systerm
|
|
Cabinet
|
MDF ,Painted finish
|
MDF ,Painted finish
|
MDF ,Painted finish
|
|
LF driver
|
1x18inch,4'VC,
125OZ, aluminium chassis
|
2x18inch,4'VC,
125OZ, aluminium chassis
|
1x 12inch, 2.5"VC,
50Oz magnet,steel basket
|
|
HF driver
|
None
|
None
|
1.35 VC Titanium
|
|
Sensitivity
|
98dB
|
98dB
|
96dB
|
Frequency
response
|
35-300hz
|
35-300hz
|
50-20Khz
|
|
RMS Power
|
500W
|
500W
|
300 W
|
|
Max Power
|
1000W
|
1000W
|
600 W
|
|
Impedance
|
8 Ohm
|
8 Ohm
|
8 Ohm
|
|
Crossover
|
150Hz
|
150Hz
|
2.5Khz
|
|
Model
|
PC12FA
|
PC15F
|
PC15FA
|
|
Type
|
2 way
,full arrange active systerm
|
2 way ,
full arrange passive systerm
|
2 way ,
full arrange active systerm
|
|
Cabinet
|
MDF ,Painted finish
|
MDF ,Painted finish
|
MDF ,Painted finish
|
|
LF driver
|
1x 12inch, 2.5"VC,
50Oz magnet,steel basket
|
1x 15 inch, 3"VC,
60 Oz magnet,steel basket
|
1x 15 inch, 3"VC,
60 Oz magnet,steel basket
|
|
HF driver
|
1.35 VC Titanium
|
1.75"VC Titanium
|
1.75"VC Titanium
|
|
Sensitivity
|
96dB
|
98dB
|
98dB
|
Frequency
response
|
50-20Khz
|
45-20Khz
|
45-20Khz
|
|
RMS Power
|
300 W
|
350 W
|
350 W
|
|
Max Power
|
600 W
|
700 W
|
700 W
|
|
Impedance
|
8 Ohm
|
8 Ohm
|
8 Ohm
|
|
Crossover
|
2.5Khz
|
2.5Khz
|
2.5Khz
|
|
