Model Number:
|
RX712ADSP
|
RX715ADSP
|
|
Type
|
2 way ,full arrange active system
|
2 way ,full arrange active system
|
|
Cabinet:
|
MDF, Plywood
|
MDF, Plywood
|
|
LF driver
|
1x 12 inch, 2.5"VC,
|
1x 15 inch, 3"VC,
|
|
60 Oz magnet,
|
80 Oz magnet,
|
|
HF driver
|
1.75"VC /44.4mmTitanium
|
1.75"VC /44.4mmTitanium
|
|
Sensitivity
|
125dB
|
127dB
|
|
Amplifier:
|
DSP Class d,BI-AMP
|
DSP Class d,BI-AMP
|
|
Frequency response
|
50-20Khz
|
45-20Khz
|
|
RMS Power
|
400 W
|
500 W
|
|
Max Power
|
800 W
|
1000 W
|
|
Impedance
|
8 Ohm
|
8 Ohm
|
|
Crossover
|
2.5Khz
|
2.2Khz
|
|
Outer carton:
|
41.5*41.5*65CM
|
49*48.5*76CM
|
|
G.W/N.W:
|
20KG/18.5KG
|
27.5KG/25KG
|
|
CBM/Ctn:
|
0.11CBM
|
0.18CBM
|
|
|
|
|
|
Model Number:
|
RX725ADSP
|
RX7103ADSP
|
|
Type
|
2 way ,full arrange active system
|
2 way ,full arrange active system
|
|
Cabinet:
|
MDF, Plywood
|
MDF, Plywood
|
|
LF driver
|
2x 15 inch, 3"VC,
|
3x 10 inch, 2.5"VC,
|
|
80 Oz magnet,
|
80 Oz magnet,
|
|
HF driver
|
1.75"VC /44.4mmTitanium
|
1.75"VC /44.4mmTitanium
|
|
Sensitivity
|
130dB
|
130dB
|
|
Amplifier:
|
Class d,DSP,BI-AMP
|
Class d,DSP,BI-AMP
|
|
Frequency response
|
45-20Khz
|
50-20Khz
|
|
RMS Power
|
700 W
|
700 W
|
|
Max Power
|
1500 W
|
1500 W
|
|
Impedance
|
8 Ohm
|
8 Ohm
|
|
Crossover
|
2.2Khz
|
2.2Khz
|
|
Outer carton:
|
61*49*117CM
|
46*36*108.5CM
|
|
G.W/N.W:
|
41KG/38KG
|
32KG/30KG
|
|
CBM/Ctn:
|
0.35CBM
|
0.18CBM
|
|
|
|
|
|
Model Number:
|
RX715SUBADSP
|
RX718SUBADSP
|
|
Type
|
Active system
|
Active system
|
|
Cabinet:
|
MDF, Plywood
|
MDF, Plywood
|
|
LF driver
|
1x 15"subwoofer, 3"VC,
|
1x 18"subwoofer, 3"VC,
|
|
80 Oz magnet,
|
80 Oz magnet,
|
|
HF driver
|
N/M
|
N/M
|
|
Sensitivity
|
129dB
|
130dB
|
|
Amplifier:
|
Class d,DSP,BI-AMP
|
Class d,DSP,BI-AMP
|
|
Frequency response
|
40-150hz
|
35-150hz
|
|
RMS Power
|
800 W
|
1000 W
|
|
Max Power
|
1600 W
|
2000 W
|
|
Impedance
|
8 Ohm
|
8 Ohm
|
|
Crossover
|
150hz
|
150hz
|
|
Outer carton:
|
61.5*52.5*67CM
|
71.5*59.5*76.5CM
|
|
G.W/N.W:
|
32KG/30KG
|
44KG/41KG
|
|
