General  Specification C18600LF
Norminal Diameter :    476mm/18inch
Power Rating :        1000W
Norminal Impedance :  8Ohm
Sensitivity :      97dB
Frequency Range :    36Hz-2kHz
Chassis Type: Aluminium
Magnet Type:    Ferrite Magnet
Magnet Weight :     220x110x25mm/125OZ
Voice Coil ;    4"/99.2mm
Coil Material    SV, Inside -out
Former Material :    Glass Fiber
Voicecoil Winding Width:    25mm
Cone/Surround Material :     Paper/Cloth
Suspension :   Double Spider
X-mas:     ±6.0mm
N/G  Weight  13/14kg
Dimension WxDxH 51x51x27cm
Thiele & Small Parameters
Re  5.3Ohm
Fs 36Hz
Mms 177g
Mmd 152
Qms 7.6
Qes 0.48
Qts 0.44
Vas 214 lt
BL 21.5 Tm
SD 0.133m2
Features
2000 Watts  Max Power Handling
Ferrite Magnet
Double Spider Suspension
Die Cast Aluminium Chassis
