General  Specification 18NW127
Norminal Diameter :    18inch
Power Rating :        1000W
Norminal Impedance :  8Ohm
Sensitivity :      96dB
Frequency Range :    35HZ-1.5KHZ
Chassis Type: Aluminium
Magnet Type:    Neodymium
Magnet Weight :     120x14mm
Voice Coil ;    5"/ 127  mm
Coil Material    SV Inside-out
Former Material :    Glass Fiber
Voicecoil Winding Width:    24mm
Cone/Surround Material :     Paper/Cloth
Suspension :   Double Spider
X-mas:     9mm
N/G  Weight  10/11 kg
Dimension WxDxH 51x51x27cm
Thiele & Small Parameters
Re  6.2 ohm
Fs 45HZ
Mms 267g
Mmd 270g
Qms 6.64
Qes 0.47
Qts 0.44
Vas 95.54
BL 29.5
SD 123
Features
2000 Watts  Max Power Handling
Neodymium Magnet
Double Spider Suspension
Die Cast Aluminium Chassis
