Model 06C38 08C50 10C50
Norminal Diameter 6" 8" 10"
Impedance 8Ohm 8Ohm 8Ohm
RMS/MAX Power 100/200W 180/350W 250/500W
Sensitivity 94dB 95dB 95dB
Frequency Range 55Hz-3KHz 55Hz-3KHz 46Hz-3.5KHz
Voice Coil 1.5" 2" 2"
Magnet 30OZ  120x60x20 30OZ 120x60x20 40 OZ  134x60x20



Model 12C76 15C76  18C100
Norminal Diameter 12" 15"  18"
Impedance 8 Ohm 8 Ohm 8 Ohm
RMS/MAX Power 300/600W 350/700W 600/1200W
Sensitivity 96dB 97dB 98dB
Frequency Range 45Hz-3.5KHz 45Hz-3KHz 35Hz-3Khz
Voice Coil 3" 3" 4"
Magnet 60OZ 170x85x20 78OZ 190x90x20 100OZ 220x110x20
