General  Specification 15XS 18XS
Norminal Diameter : 393mm/15inch 465mm/18inch
Power Rating : 500W 700W
Norminal Impedance : 8Ohm 8Ohm
Sensitivity : 97dB 97.5dB
Frequency Range : 45Hz-5kHz 40Hz-3kHz
Chassis Type: Aluminium Aluminium
Magnet Type: Ferrite Magnet Ferrite Magnet
Magnet Weight : 125 OZ  220*110*25 125 OZ  220*110*25
Voice Coil ; 4"/99.2mm 4"/99.2mm
Coil Material SV,Inside-out SV,Inside-out
Former Material : Glass Fiber Glass Fiber
Voicecoil Winding Width: 23mm 25mm
Cone/Surround Material : Paper/Cloth Paper/Cloth
Suspension : Single Spider Double Spider
X-mas: ±4.0mm ±6.0mm
N/G  Weight 13/14kg 16/18kg
Dimension WxDxH 44x44x25cm 51x51x27cm
