General  Specification 15HP1030 18HP1030
Norminal Diameter : 393mm/15inch 465mm/18inch
Power Rating : 800W 1000W
Norminal Impedance : 8Ohm 8Ohm
Sensitivity : 97dB 97.5dB
Frequency Range : 45Hz-5kHz 35Hz-3kHz
Chassis Type: Aluminium Aluminium
Magnet Type: Ferrite Magnet Ferrite Magnet
Magnet Weight : 125 OZ  220*110*25 125 OZ  220*110*25
Voice Coil ; 4"/99.2mm 4"/99.2mm
Coil Material SV,Inside-out SV,Inside-out
Former Material : Glass Fiber Glass Fiber
Voicecoil Winding Width: 28mm 28mm
Cone/Surround Material : Paper/Cloth Paper/Cloth
Suspension : Single Spider Double Spider
X-mas: ±4.0mm ±6.0mm
N/G  Weight 13/14kgkg 16/18kg
